Common Inflation Pressure Guide
1. On / Off
Long-press the Power button to turn on. The screen lights for ~1.5 s, runs self-check, and the inflator enters standby. It auto-powers off after 2 minutes of inactivity, or long-press Power to shut down manually.
2. Connect the Air Hose
Screw the metal end of the hose firmly onto the air outlet on top of the inflator.
Presta Valve Adaptor :
Unscrew the cap on the Presta Valve.
Thread the "Presta valve adaptor" onto the tyre's Presta valve.
Push the air hose connector firmly into the adaptor and lock to start inflation.
After inflation, remove the hose and screw the valve cap back on.
Ball Needle:
For inflating basketballs, footballs and similar items, use the "ball needle".
Attach the "ball needle" to the hose connector, then insert the needle into the ball's air port to inflate.
When finished, pull the "ball needle" straight out of the air port.
3. Measure Tyre Pressure
When the unit is powered on and the air hose is attached to the item, the top row of white digits displays the preset target pressure, and the bottom row displays the item's real-time pressure.
4. Checking Recommended Inflation Pressure
For safety, read the inflation recommendations in the product manual of the item to be inflated and determine the correct pressure to avoid accidents or injury caused by over- or under-inflation.
For bicycles, e-bikes, and other vehicles, the recommended tyre pressure is usually marked on the tyre sidewall. The recommended car pressure is on the vehicle's tyre placard. For other items, refer to the product's instructions.
For balls such as basketballs and footballs, the recommended pressure is usually marked near the inflation port.
Tip: The recommended pressure ranges below are for reference only. Always follow the manual of the item you are inflating. Pressure of ballon, ball etc. is unable to stops automatically due to the pressure is lower than the minimum pressure.
Jump Start Guide
1. Preparation for Emergency Start
Turn off the vehicle ignition and all external electrical accessories.
Open the hood and find the vehicle battery.
2. Connect the Jumper Clamp to the Main Unit
Insert the jumper clamp plug into the designated port on the inflator.
The clamp's indicator will flash red and green alternately, indicating the jumper clamp is activated.
3. Connect the Jumper Clamp to Vehicle Battery
Clip the red clamp to the battery positive (+) terminal and the black clamp to the negative (–) terminal.
If the indicator turns green, the connection is correct—proceed to the next step.
If the indicator turns red and the beeper alarms, the polarity is reversed; reconnect the clamps correctly.
Note: If the red light is on and the clamps are not firmly attached, an alarm may sound. It may also indicate the battery voltage is below 14V; recharge the battery before trying again.
4. Start the Vehicle
Start the vehicle normally
5. Remove the Jumper Clamp
After the engine starts, remove the jumper clamps from the battery's positive and negative terminals.
6. Unplug the Jumper Clamp from the device.
Unplug the clamp from the main unit.
